A vapor barrier is a polyethylene sheeting system installed on the ground and walls of a crawl space or basement to block ground moisture from migrating into the structural environment above. Understanding what a proper vapor barrier consists of, however, goes well beyond simply laying plastic on the floor.
Standard 6-mil poly sheeting has a relatively high vapor permeance rating, meaning it allows some moisture vapor to pass through over time, particularly as it ages and develops micro-perforations from foot traffic and environmental factors. A 20-mil reinforced vapor barrier significantly reduces vapor diffusion and resists punctures from gravel, debris, and service personnel working in the crawl space.
Overlapping sheets by 12 inches or more at seams and securing them with butyl tape creates a continuous, mechanically bonded membrane that resists separation as the sheeting settles and moves over time. We use butyl tape exclusively for seam sealing, both because of its long-term adhesion to polyethylene and its resistance to moisture and temperature cycling.
Covering only the floor and stopping the barrier at the wall-floor junction leaves the porous block or concrete foundation walls as an open pathway for moisture to enter the crawl space environment. The combination of floor coverage, properly lapped and taped seams, and full wall coverage to the sill plate creates a complete moisture envelope that dramatically reduces crawl space humidity and protects the wood framing above.
It also creates ideal conditions for mold and mildew growth on wood surfaces and insulation, contributing to indoor air quality problems in the living space above. A well-installed vapor barrier is also a prerequisite for effective dehumidifier integration in crawl spaces where mechanical moisture extraction is warranted.
Every installation meets or exceeds Mount Vernon, NY building standards.
The materials we install in Mount Vernon are built to last decades, not years.
We extend the barrier up every wall to the sill plate, closing the moisture entry pathway that floor-only installations miss.
Our vapor barrier installations carry a written warranty covering materials and workmanship.
We install reinforced polyethylene sheeting across the entire crawl space floor with full wall coverage and butyl-taped seams throughout.
We remove deteriorated existing barriers, prepare the substrate, and install a properly spec'd replacement that meets current installation standards.
The installation includes full seaming, perimeter taping, and wall coverage to the base of the finished wall or sill plate.
This combination approach addresses both vapor diffusion and water management in a single installation.
Full crawl space encapsulation combines a complete vapor barrier system with a dedicated dehumidifier sized for the space to achieve and maintain target humidity levels year-round.
We offer post-installation inspections for vapor barriers installed by other contractors, as well as for our own older installations, to assess barrier condition, seam integrity, and wall coverage completeness.
We measure the space, assess existing moisture conditions, document any existing barrier or mold, and identify all penetrations that will need to be addressed in the installation
Based on site conditions, we specify the appropriate mil rating, calculate material quantities, and plan the seaming layout for maximum coverage and minimum waste
Sheeting is laid, overlapped at 12 inches minimum, taped with butyl tape at all seams, and extended up all walls with mechanical fastening at the top edge
We walk through the completed installation with you, confirm all seams and coverages are complete, and provide written warranty documentation before leaving
"We had a previous vapor barrier installation that was barely 6-mil and had separated seams throughout. The humidity in our crawl space was unacceptable and we were starting to see mold on the floor joists. JCB Waterproofing and Construction came in, took out the failing old barrier, and installed a proper system that actually works. The difference in our indoor air quality was noticeable within a week."
"Very professional team that explained the difference between the grades of vapor barrier sheeting before recommending anything. The 20-mil they installed is rock solid and the seams are all properly taped. We can already see the humidity meter reading dropping consistently."
"The crew extended the barrier all the way up the walls to the sill plate, which the contractor who did our original installation did not do. The proper wall-to-sill installation finally completed our moisture protection. Great work from a team that clearly knows what they are doing."
Our certified team is ready to assess your crawl space and provide a clear, honest recommendation
